| Код |
Значение |
| |
|
| Шасси |
BE-4 и BE-4A |
| 00 |
No Error |
| 02 |
Chroma 4 not acknowledging I2C transmission, NVM O.K. |
| 03 |
Chroma 4 fault (not O.K.) — flags |
| 04 |
Chroma 4 — no H flyback |
| 05 |
Chroma 4 — stack overflow |
| 06 |
Protection input (pin 52) high |
| 07 |
NVM not acknowledging I2C transmission, Chroma 4 O.K. |
| 08 |
NVM & Chroma 4 — No I2C acknowledge |
| 09 |
General I2C error |
| |
|
| Шасси |
BE-5 |
| 00 |
No Error |
| 01 |
General I2C bus 1 error (SDA1 or SCL1 are being held low) |
| 10 |
NVM does not acknowledge on IIC bus 0 transmission |
| 20 |
Tuner does not acknowledge on IIC bus 1 transmission |
| 30 |
Jungle does not acknowledge on IIC-bus 1 transmission |
| 31 |
Jungle fault (not O.K.) — flags |
| 32 |
Jungle — no H flyback |
| 33 |
Jungle — stack overflow |
| 40 |
Sound processor does not acknowledge on IIC bus 1 transmission |
| 90 |
Protection input: X-ray protection |
| 91 |
Protection error: No V synchro |
| |
|
| Шасси |
BE-3 и RE-2 |
| 00 |
No Error |
| 02 |
Protection circuit trip |
| 03 |
IIC SCL low |
| 04 |
IIC SDA low |
| 05 |
IIC SDA and SCL low |
| 06 |
Jungle/Chroma controller does not acknowledge |
| 07 |
Video switch does not acknowledge |
| 08 |
Tuner does not acknowledge |
| 09 |
MSP does not acknowledge |
| 10 |
NVM does not acknowledge |
| 11 |
M3L TXD low |
| 12 |
M3L RXD low |
| 13 |
M3L enable low |
| 14 |
M3L TXD and RXD low |
| 15 |
Compact Text test fail |
| 16 |
AV-switch cannot power on reset |
| 17 |
Cannot initialize jungle |
| 18 |
NVM acknowledge fail after initialization |
| 19 |
Multiple devices do not acknowledge |
| 20 |
Compact text run-time failure |
| 21 |
AV-switch response failure after power up |
| 22 |
Jungle/Chroma controller response failure after power up |
| 23 |
Compact text does not respond |
| 24 |
Sound Processor run-time failure |
| 25 |
M5L bus clock low time-out after data sent (runtime failure) |
| 26 |
M5L bus clock low time-out after data sent (power up) |
| 27 |
M3L bus clock low time-out after data sent (initialisation) |
| 28 |
DSP run-time failure |
| |
|
| Шасси |
LE-1 |
| 00 |
No Error |
| 01 |
No communication on I2C bus 1 and bus 2. |
| 02 |
No communication on I2C bus 1. |
| 03 |
No communication on I2C bus 2. |
| 10 |
No communication with A board |
| 11 |
CXP85332 (Subcontroller) does not respond (A board) |
| 12 |
ST24C16 (NVM) does not respond (A board) |
| 13 |
SDA5273 (Megatext) does not respond (A board) |
| 14 |
TDA6812 (Soundprocessor) does not respond (A board) |
| 15 |
SAA7283 (NICAM decoder) does not respond (A board) |
| 16 |
CXA1839Q (Video Controller) does not respond (A board) |
| 17 |
TDA7317 (Equalizer) does not respond (A board) |
| 18 |
CXA1315 (White Balance) does not respond (A board) |
| 19 |
CXA2011 (White Balance) does not respond (A board) |
| 20 |
No communication with B board |
| 21 |
CXD2030 (Main Chroma Decoder) does not respond (B board) |
| 22 |
CXD2031 (Twin Picture IC) does not respond (B board) |
| 23 |
CXD2032 (Sampling Rate Converter) does not respond (B board) |
| 24 |
CXD2030 (Sub Chroma Decoder) does not respond (B board) |
| 25 |
CXA1840 (Main CRT driver) does not respond (B board) |
| 26 |
CXA1840 (Sub CRT driver) does not respond (B board) |
| 28 |
RGB8443 (RGB/YUV) does not respond (B board) |
| 30 |
No Communication with J-board |
| 31 |
CXA1855 (AV-Switch) does not respond (J-board) |
| |
|
| Шасси |
Шасси FE-1 |
| 00 |
Нет ошибки |
| 02 |
Цепь защиты по току линии +В(выв 52 контроллера) |
| 04 |
Нет кадровых импульсов обратного хода |
| 05 |
Нет обратной связи по току катодов |
| 06 |
Проблемы шины I2C при вкл ТВ |
| 07 |
Нарушена связь контроллера с EEPROM (NVM) IC004 при вкл ТВ |
| 08 |
Нет связи контроллера c IC301_CXA_2060AS по шине I2C |
| 09 |
Нет связи контроллера c тюнером TU101 по шине I2C (только в стерео моделях) |
| 10 |
Нет связи контроллера cо звук проц TDA9875_IC1101 по шине I2C (только в стерео моделях) |
| |
|
| Шасси |
Шасси FE-2 |
| E02 |
OCP (защита по току питания +В) |
| E03 |
OVP N/A (защита по перенапряжению) |
| E04 |
VSYNC (нет кадрового импульса синхронизации) |
| E05 |
IKR (ошибка по АББ) |
| E06 |
IIC (ошибка по шине I2C) |
| E07 |
NVM (ошибка памяти EEPROM) |
| E08 |
JUNGLE (ошибка видеопроцессора) |
| E09 |
TUNER (ошибка тюнера) |
| E10 |
SOUNDP (ошибка звукового процессора) |
| E11 |
8V (нет питания 8 вольт) |
| |
|
| Шасси |
AE-4 |
| 00 |
No Error |
| 0-10 |
5V (1) Supply Voltage fault |
| 0-30 |
8V Supply Voltage fault |
| 0-40 |
10V/8V Supply Voltage fault |
| 0-60 |
135V Supply Voltage fault |
| 1-00 |
No Communication with A board |
| 2-00 |
No Communication with B board |
| 3-00 |
No Communication with D board |
| 4-00 |
No Communication with T board |
| 5-00 |
No Communication with Q board |
| 1-01 |
A board: ST24C16 (NVM) does not respond |
| 1-02 |
A board: SDA5273/75 (Megatext) does not respond |
| 1-03 |
A board: TVF-01-XXX (Main Tuner) does not respond |
| 1-04 |
A board: CXA1855 (AV-switch) does not respond |
| 1-05 |
A board: CXD2053 (Auto Wide IC) does not respond |
| 1-06 |
A board: TDA9143/44 (Main Color decoder) does not respond |
| 1-07 |
A board: TDA9143 (Sub Color Decoder) does not respond |
| 1-08 |
A board: TDA9170 (Artificial Intelligence) does not respond |
| 1-09 |
A board: SDA9288 (PIP) does not respond |
| 1-10 |
A board: MSP3400/10 (Audio Processor) does not respond |
| 1-11 |
A board: TC9397F (Audio Effect Processor) does not respond |
| 2-01 |
B board: P87C654 (Featurebox) does not respond |
| 2-02 |
B board: SDA9280 (D/A Converter) does not respond |
| 2-03 |
B board: SDA9361 (Deflection) does not respond |
| 2-04 |
B board: TDA4780 (Video Processor) does not respond |
| 3-01 |
D board: TDA7309 (Headphone Processor) does not respond |
| 4-01 |
T board: TVF-01-XXX (Sub Tuner) does not respond |
| 4-02 |
T board: CXA1875 (Port Expander) does not respond |
| |
|
| Шасси |
GE-1 |
| 00 |
No Error |
| 0-01 |
No Communication on I2C Bus 1 |
| 0-02 |
No Communication on I2C Bus 2 |
| 1-00 |
No Communication with A board |
| 2-00 |
No Communication with A1 board |
| 3-00 |
No Communication with B board |
| 4-00 |
No Communication with B1 board |
| 5-00 |
No Communication with D1 board |
| 6-00 |
No Communication with J board |
| 7-00 |
No Communication with Q board |
| 1-01 |
A board: ST24C32 (NVM) does not respond |
| 1-02 |
A board: SDA5273/75 (Megatext) does not respond |
| 1-03 |
A board: CXA2101 (Multi Component Processor) does not respond |
| 1-04 |
A board: SDA9361 (Deflection) does not respond |
| 1-05 |
A board: TVF-01-XXX (Main Tuner) does not respond |
| 1-06 |
A board: TVF-01-XXX (Sub Tuner) does not respond |
| 1-07 |
A board: MSP3410D (Audio Processor) does not respond |
| 1-08 |
A board: CXA1875 (Port Exp. for Sub Tuner ctrl.) does not respond |
| 1-09 |
A board: CXA1315 (Port Exp. for UYV MCP Gain control) does not respond |
| 1-10 |
A board: PCF8574 (General Port Expander 1) does not respond |
| 1-11 |
A board: PCF8574 (General Port Expander 2) does not respond |
| 1-12 |
A board: PCF8574 (Interrupt Port Expander) does not respond |
| 1-13 |
A board: PCF8593 (Real Time Clock) does not respond |
| 1-14 |
A board: TC55257 memory test failed or external RAM |
| 2-01 |
A1 board: TMS57053 (DSP) does not respond |
| 3-01 |
B board: TDA9144 (Color decoder of main picture) does not respond |
| 3-02 |
B board: TDA9143 (Color decoder of sub picture) does not respond |
| 3-03 |
B board: CXD2072Q (MID2) does not respond |
| 3-04 |
B board: CXD2053 (Autowide IC) does not respond |
| 4-01 |
B1 board: P87C654 (Feature Box) does not respond |
| 4-02 |
B1 board: SDA9280 (D/A Converter) does not respond |
| 5-01 |
D1 board: CXA1875 (General Port Expander 3) does not respond |
| 6-01 |
J board: CXA1855 (AV Switch) does not respond |
| 6-02 |
J board: TDA7309 (Headphone processor) does not respond |
| 7-01 |
Q board: CXK8625 (PALplus decoder) does not respond |
| 7-02 |
Q board: SAA7185 (PAL encoder) does not respond |
| |
|
| Шасси |
AZ1- |
| 2 |
Неисправность системы питания (Main Power Error) |
| 3 |
Неисправность DC-источников на плате ВАА, звукового тракта или видеосистемы (DC_ALERT1/ Audio Error/ Motion flow Error) |
| 4 |
Неисправность системы отображения (Balancer Error) |
| 5 |
Ошибка контроллера таймингов T-CON или ошибка идентификации ЖК панели (T-CON Error/ Panel ID NVM Error) |
| 6 |
Ошибка системы подсветки ЖК панели (Backlight Error) |
| 7 |
Превышен порог температуры (Temp Error) |
| |
|
| Шасси |
LЕ-1 |
| 1 |
защита лампы |
| 2 |
нет фильтра-крышки лампы |
| 3 |
защита вентилятора |
| 4 |
защита по температуре |
| 9 |
нарушен обмен по линии I2C |
| 10 |
память EEPROM IC 1023 ST24C16 |
| 11 |
контроллер IC1001 |
| 12 |
IC4001 CXA1840 |
| 13 |
IC4004 CXD2030 |
| 14 |
IC4021 CXD2031 |
| 15 |
IC3008 CXD2428 |
| 16 |
IC1032 CXA_1839 |
| 17 |
IC1030 CXA_2011 |
| 18 |
IC4002 TDA_8443 |
| 19 |
TTX IC1020 SDA5273 |
| 20 |
IC1015 TDA6812 |
| 21 |
IC5004 CXD2412, IC1031 CXA1315 |
| 22 |
IC2401 CXA1855 |
| |
|
| Шасси |
AЕ-2B |
| 1 |
SDA low II C BUS |
| 2 |
EEPROM X24C16 |
| 3 |
Tuner PII SDA3202 |
| 4 |
Color Decoder TDA9145 |
| 5 |
RGB Jungle CXA1587S |
| 6 |
Sound Processor TDA6612 |
| 7 |
V deflection CXD2018 |
| 8 |
AV switch CXA1545 |
| 11 |
Tele Text SDA5248 |
| 13 |
V Protection |
| |
|
| Шасси |
ВЕ-3В, BE-4A |
| 2 |
Память IC002 |
| 3 |
Память IC002 |
| 4 |
Память IC002 |
| 5 |
Память IC002 |
| 6 |
Память IC002 |
| 7 |
Память IC002 |
| 8 |
Память IC002 |
| 9 |
Память IC002 |
| 10 |
Teletext IC1001, 1002 |
| 11 |
Видео процессор IC301 |
| 12 |
AV — коммутатор IC401 |
| 13 |
Неисправность тюнера TU101 (ЕСС 411)-(ххх) — равноценная замена |
| 15 |
Канал звука IC1200 |
| |
|
